MCA 280
MCA 280
All essential data about our MCA 280:
CAN Interface
- 1 independent CAN interface supports standard SAE J1939
- CAN interface 2.0B (11-Bit-, 29-Bit-dentifier)
- Transfer rate: configurable up to 1 Mbit/s
Input Signals
- 3 analogue inputs (U, I, R)
- 2 frequency inputs
- Up to 16 digital inputs
Output Signals
- 2 digital outputs max. 1,5 A
- 1 voltage output buzzer output max. 25 mA
TFT Colour Display
- Resolution: 240 x 320 px
- Diagonal: 2,8“
- Colour: RGB
- Brightness: 250 cd/m²
Electrical Specifications
- Nominal voltage: 12 Volt / 24 Volt
- Operating voltage: 8 …32 Volt
- Temperature range: -40 bis +85°C
- Protection: short-circuit, overload and pole protected
- EMV-compatibility: EN 13309; ISO 13766; ECE R10 Rev. 5
Mechanic
- Protection degree: IP67 (front); IP40 (rear)
- Dimensions: Installation aperture 100 mm; Installation depth 34 mm; Blind overhang 3,2 mm
Get the comprehensive product brochure for our MCA 280 now!
